Main Features
- Mains Energy, Device Energy, Line Loss Energy Measurement
- Bidirectional Energy Directions
- Suitable For DC E-mobility Charging Stations & Any Sub-billing Applications
- MID & PTB & CE & UL Certificate
Specifications and Main Technical Indicators：
| Specification | J5025-AVG |
Type | DC Electronic Meter |
Standards | EN 50470-4, IEC 62053-41, IEC 62052-31,
UL 61010-1, UL 61010-2-030 |
Voltage
Umax
Umin | 1000V
40V |
Current
Minimum current Imin
Reference current In
Maximum current Imax
Starting current Ist | 1A
40A
200A
0.4%In |
Accuracy | Class C/0.5 |
Pulsating Indicator
Pulsating (meter constant) | LED
5000imp/kWh |
Environment
Temperature range | Operation: -40 80℃
Storage: -40 85℃ |
Protection Degree | IP 20 |
Insulation Class | II |
Typical Power Consumption
Voltage circuit active/apparent power at Un
Current circuit apparent power at Ib | ＜0.5W
＜0.04W/A Imax |
LCD Display | Dot Matrix type, backlight supported |
Auxiliary Power Supply | ＜ 1 W |
Communication Interface | 2 RS485 port, upto 921600bps |
Weight Of Meter | About 0.4kg |
Dimension(LxWxD) | 105 x 71 x 80mm |
